Aluminum profile 40x40 Light Blk
TOP
Configure profile dimensions
Thread count is per piece: one-sided = 1, two-sided = 2
Total length: 0 cm |
Total thread taps: 0
Note: Max single length 6000 mm / 600 cm. Overlength > 1980 mm / 198 cm: pickup/request only.
Technical features
Material: EN AW 6063 T66
Second moment of area Ix: 7.33
cm4
Second moment of area Iy: 7.33
cm4
Section modulus Wx: 3.66
cm3
Section modulus Wy: 3.66
cm3
Weight: 1.368 kg/m
Initial guidance on the load capacity of our aluminium profiles.
Ideal for project planning, directly usable online.
Ideal for project planning, directly usable online.
Safety notes for using aluminium profiles
- Install connections correctly and tighten screws to the recommended torque.
- Regularly inspect all connections, especially under dynamic loads.
- Use only within the intended material and design limits.
- For safety-critical applications, consult a structural engineer or specialist planner.
- Use appropriate protective equipment during assembly work.
Note: The LoadCheck provides initial guidance and does not replace a structural calculation.
